THE EOS4 SERIES ARE A CATEGORY 4 SAFETY LIGHT CURTAIN. THEY ARE COMPACT WITH A COMPETITIVE PERFORMANCE AND INNOVATIVE FEATURES. EOS4 MODEL OPTIONS INCLUDE INTEGRATED SAFETY FUNCTIONS SUCH AS SELF-MONITORING-2 SAFETY PNP STATIC OUTPUTS, CONTROL OF EXTERNAL CONTACTORS(EDM), AND SELECTABLE AUTOMATIC OR MANUAL RESTART. ESO4 CURTAIN CONNECTION AND INSTALLATION ARE EASY, THANKS TO M12 CONNECTORS AND THE USE OF UP TO 100 METERS OF UNSHIELDED CABLE.

ABOUT THIS MODEL:

TYPE 4, SIL3, SILCL3, PL E, CAT. 4.
DESIGNED TO SECURE OPERATORS WORKING IN POTENTIALLY EXPLOSIVE ATMOSPHERES.
INTEGRATED ANTI-CONDENSATION SYSTEM.
HARDWARE CONFIGURATION: NO PROGRAMMING NECESSARY, EASY TO INSTALL AND REPLACE.
UNSHIELDED CABLES UP TO 100 M CAN BE USED TO CONNECT THE SAFETY LIGHT CURTAIN.
WHAT'S IN THE BOX: EMITTER, RECEIVER, STANDARD FASTENING BRACKETS, PRE-WIRED CONNECTION CABLE

SAFETY CERTIFICATIONS: CE, TÜV, UL, Atex

SAFETY LIGHT FOR HEATED WATERTIGHT USE

SPECIFICATIONS
DETECTION LENGTH:	610 MM
RESOLUTION:	30 MM
HEIGHT:	910 MM
WIDTH:	200 MM
DEPTH:	145 MM
WEIGHT:	6.58 KG
DETECTION TYPE:	ACCESS CONTROL
ADD ONS:	ESD MAT 10M LEAD CABLE
RESTART MODE:	AUTOMATIC
