Item # 33-45903S-7
MODULAR SOLUTIONS FOOT
45MM X 90MM (3) SIDED FOOT W/12MM FLOOR ANCHOR HOLES, HEIGHT = 105MM
- $32.89 / EA
- Manufacturer: MODULAR SOLUTIONS
- UM: EA
- Weight: 1.75
GENERAL SPECIFICATIONS:
- MOUNTING FOOT 3 SIDED FOR 45 X 90
- PARTICALLY ENCLOSED AND SHORT
- METALIC IN COLOR
- MATERIAL: CAST ALUMINUM
TECHNICAL:
- WITH 12MM FLOOR ANCHOR HOLES
- HEIGHT - 105MM WITH UP TO 40MM OF HEIGHT ADJUST
- WORKS WITH 3/8 IN X 3 IN WEDGE ANCHOR 24-383-0
- WORKS WELL WITH PROFILES 10-4590
INFO:
- WORKS WITH 3/8 IN X 3 IN WEDGE ANCHOR 24-383-0
- WORKS WELL WITH PROFILES 10-4590
Click image to enlarge
Specifications
| PROFILE USED WITH | 45 X 90 |
| NUMBER OF SIDES | 3 MOUNTING SIDES |
| MOUNTING HARDWARE | WITH HARDWARE |
Item # 33-45903S-7
MODULAR SOLUTIONS FOOT
45MM X 90MM (3) SIDED FOOT W/12MM FLOOR ANCHOR HOLES, HEIGHT = 105MM
Documents
×
